Konscious Auxichill introduces Air/Water-Cooled Air Chillers for flexible and efficient air cooling applications. Designed to provide chilled air directly without ducting or AHUs, these chillers are ideal for modular industrial spaces, warehouses, and temporary cooling zones. With dual cooling options (air and water), they offer enhanced versatility and efficiency.
Key Features of Air/Water-Cooled Air Chillers
- Direct Cooling Technology: Optimized for air blown film lines.
- Temperature Consistency: Maintains stable air temperature for improved film quality.
- Rapid Temperature Adjustment: Achieves desired air temperature in less time.
- Power Efficiency: Adjusts power consumption based on actual requirements; features hot gas bypass for capacity control at partial loads.
- Easy Access Design: Housing allows for straightforward access to components.
- Microcontroller: Includes text display, flow diagram, and fault indication.
- Digital Display: Shows air inlet and outlet temperatures.
- Air Flow Switch: Indicates low air flow alarm.
Why Choose Konscious Auxichill Air Chillers?
- Dual mode cooling – air and water – for site flexibility
- No ducting or AHUs required – direct chilled air output
- Best suited for open or semi-open industrial spaces
- Low footprint & mobile models available for events or rentals
- Custom options for spot cooling or large hall conditioning
Applications
( KACAAC & KACWAC Series ) R410A
| MODEL (KACAAC/KACWAC) | KAC 15 | KAC 20 | KAC 30 | KAC 40 | KAC 50 | KAC 60 | KAC 80 | KAC 90 | |
| Cooling Capacity | kW | 24 | 34 | 51 | 66 | 75 | 83 | 93 | 125 |
| Absorbed Power | kW | 6.4 | 9.4 | 13.4 | 17.8 | 20.0 | 22.3 | 21.2 | 28.7 |
| Max. Air Flow | m’/ hr | 1500 | 2000 | 3000 | 4000 | 5000 | 6000 | 8000 | 9000 |
| Min. Air Flow | m’/ hr | 600 | 800 | 1200 | 1600 | 2000 | 2400 | 3200 | 3600 |
| Air in/out connection | mm | 200 | 200 | 200 | 200 | 300 | 300 | 300 | 300 |
| Temperature Range | ⁰C | +5 up to +20 | |||||||
| Air temperature Inlet
& % R .H. |
°C & % R.H. | 40 °C & 40% R .H. | |||||||
| Air temperature
Outlet |
⁰C | 10 ⁰C | |||||||
| Water to Condenser
@ 30 ⁰C & 3 bar |
LPM | 150 | 200 | 300 | 400 | 450 | 500 | 550 | 700 |
| Cooling Tower Capacity | TR | 12 | 16 | 24 | 32 | 35 | 40 | 44 | 65 |
|
Dimension |
L | 1230 | 1230 | 1600 | 1600 | 1600 | 1600 | 1870 | 1870 |
| w | 800 | 800 | 1200 | 1200 | 1200 | 1200 | 1380 | 1380 | |
| H | 1690 | 1690 | 1690 | 1690 | 2010 | 2010 | 2000 | 2010 | |
| Weight | Kg | 325 | 350 | 500 | 550 | 650 | 750 | 900 | 1000 |
| Electrical Connections | 415V,3Ø,50HZ | ||||||||
Technical Specifications
- Cooling Capacity: 5–100 TR
- Cooling Method: Air-Cooled or Water-Cooled (as per site)
- Compressor: Scroll or Screw (depending on size)
- Air Discharge: Top or Side via high-volume fans
- Power Supply: 3 Phase, 380–460V, 50/60 Hz
- Control Panel: Digital with Safety Interlocks & Alarm Log
- Ambient Range: Designed for up to 48°C operation
Advantages of Air/Water-Cooled Air Chillers
- Ideal for flexible and mobile cooling setups
- Eliminates the need for central air handling units
- Dual mode ensures optimal performance in any environment
- Quick installation and relocation capability
Frequently Asked Questions (FAQs)
These chillers provide chilled air directly to the space without ducts or air handlers, and support both air and water-cooled modes for site-specific adaptability.
Yes, compact models are designed for mobility and quick setup in different locations.
We offer R410A, R407C, and R134a-based models depending on cooling needs and environmental preferences.
Yes, weatherproof versions are available for rugged outdoor deployment.
