Konscious Auxichill Pvt. Ltd offers Hot Air Dryers (Non-Insulated) designed to provide economical and reliable drying for non-hygroscopic plastic granules. Suitable for applications where basic drying is required, these dryers are perfect for materials like PP, PE, and PVC. With a user-friendly interface and consistent air flow, they improve processing efficiency at an affordable cost.
Features
- Durable Construction: No aluminum casting ensures long life and reliability.
- Heater Assurance: SS 304 heater pipe guarantees no melting.
- Even Air Distribution: Designed air distribution cone for uniform airflow.
- Effective Drying: Properly dries plastic granules.
- Maintenance Access: Large access window with clamps for easy cleaning.
- Overheat Protection: Automatic mode to prevent material degradation.
- High-Pressure Blower: Optimized airflow for efficient drying.
- Temperature Capacity: Suitable for drying temperatures up to 180°C.
- Efficient Design: Smooth furnace with a 60° cone angle for thorough heat exposure.
Why Choose Konscious Auxichill Pvt. Ltd. Non-Insulated Dryers?
- Affordable drying solution for general-purpose plastics
- Quick startup and easy-to-operate
- Suitable for small to mid-scale operations
- Available in multiple hopper sizes
- Low maintenance with durable construction
Applications
KACD Series
|
MODEL |
CAPACITY (LITTER) |
DIMENSIONS L X W X H (MM) | HEATER CAPACITY (KW) | BLOWING POWER (WATTS) |
VOLTAGE |
CABLE SIZE COPPER |
MAIN MCB |
| KACD-60 | 60 | 670 x 550 x 930 | 2.7 | 90 | 415V,3PH | 1.5 SQMM | 16AMP |
| KACD-100 | 100 | 780 x 600 x 1100 | 3.9 | 200 | 1.5 SQMM | 16AMP | |
| KACD-150 | 150 | 900 x 650 x 1170 | 6 | 250 | 2.5 SQMM | 25AMP | |
| KACD-200 | 200 | 900 x 650 x 1340 | 6 | 250 | 2.5 SQMM | 25AMP | |
| KACD-300 | 300 | 1000 x 840 x 1670 | 10 | 400 | 6.0 SQMM | 40AMP | |
| KACD-400 | 400 | 1100 x 925 x 1800 | 12 | 400 | 6.0 SQMM | 40AMP | |
| KACD-600 | 600 | 1350 x 950 x 1900 | 18 | 750 | 10 SQMM | 63 AMP | |
| KACD-800 | 800 | 1400 x 970 x 2250 | 18 | 750 | 10 SQMM | 63 AMP |
Technical Specifications
- Drying Capacity: 15–300 kg/hr
- Heater Type: Tubular / Coil Type
- Temperature Range: Up to 120°C
- Blower: Compact Centrifugal Fan
- Control Panel: Digital temperature control
- Power Supply: 230V / 480V, 50 Hz, Single/Three Phase
- Material: MS Powder Coated (SS optional on request)
Advantages of Non-Insulated Drying Systems
- Cost-effective option for basic drying needs
- Simple construction makes maintenance easy
- Faster return on investment for low-budget operations
- Reliable performance for general-grade plastic materials
Frequently Asked Questions (FAQs)
Insulated dryers retain more heat and are more energy-efficient. Non-insulated dryers are more economical and suitable for basic drying needs.
They are best for non-hygroscopic plastics like PP, PE, PVC, etc.
Yes, SS construction is available on request for hygienic or high-temperature applications.
Yes, the temperature can be controlled through a digital thermostat.
