Konscious Auxichill Pvt. Ltd. offers Mould Temperature Controllers (MTC) designed to maintain precise temperature of moulds during injection molding or die casting. Available in both water and oil-based models, these systems enhance part quality, reduce cycle time, and improve process repeatability.
Key Features of Mould Temperature Controllers
- Precise Control: Microprocessor control with simultaneous display of set and actual values.
- Temperature Range: Water-based up to 95°C; oil-based up to 180°C.
- Digital Display: Clear readout of set and actual temperatures.
- Powerful Pump: High flow and high pressure for efficient operation.
- Pump Protection: Dry running protection via level monitoring device.
- Automatic Re-Feeding: Provision for automatic water re-feeding in water units.
- Corrosion Resistance: Corrosion-proof materials used in water lines.
- User-Friendly Interface: Easy control with fault indication.
- Overload Protection: Safeguards the pump from overload.
- Connection Features: Solenoid valve and NRV on process inlet/outlet connections.
- Durable Hose: High-temperature steel graded hose pipe for reliability.
Why Choose Konscious Auxichill Pvt. Ltd. MTC Units?
- Stable mould temperature for superior surface finish
- Fast heating and cooling to reduce production time
- Compact design for machine-side placement
- Precise PID controller with accurate feedback system
- Suitable for various mould sizes and materials
Applications
KAC-MTC Series
| MODEL |
CIRCULAllNG MEDIUM |
HEATING CAPACITY (KW) |
MAXIMUM TEMPERATUR |
NOMINAL COOLLING CAPACITY
(KW) |
PUMP PRESSURE (BAR) | PUMP MOTOR (KW) |
PUMP FLOW RATE (LPM) |
TANK CAPACITY (LTR) |
MAIN CABLE COPPER |
MAIN MCB |
POWER SUPPLY |
| KACMTC-06-OIL | Oil | 6 | 170 | 20 | 3.8 | 0 75 | 65 | 25 | 1.5 SQ MM | 16AMP | 415V,3PH |
| KACMTC-06-WATER | WATER | 6 | 95 | 20 | 3.8 | 0 75 | 65 | 25 | 1.5 SQ MM | 16AMP | |
| KACMTC-09-OIL | Oil | 9 | 170 | 70 | 3.8 | 0 75 | 65 | 25 | 2.5 SQ MM | 25AMP | |
| KACMTC-09-WATER | WATER | 9 | 95 | 70 | 3.8 | 0 75 | 65 | 25 | 2.5 SQ MM | 25AMP | |
| KACMTC- 12-OIL | Oil | 12 | 170 | 28 | 5 | 2. 2 | 100 | 45 | 4.0 SQ MM | 32 AMP | |
| KACMTC-12-WATER | WATER | 12 | 95 | 28 | 5 | 2. 2 | 100 | 45 | 4.0 SQ MM | 32 AMP | |
| KACMTC-18-OIL | Oil | 18 | 170 | 28 | 5 | 2. 2 | 100 | 45 | 10.0 SQ MM | 63AMP | |
| KACMTC-18-WATER | WATER | 18 | 95 | 28 | 5 | 2. 2 | 100 | 45 | 10.0 SQ MM | 63AMP |
Technical Specifications
- Temperature Control: PID Digital Controller
- Temperature Range: Water – up to 120°C, Oil – up to 200°C
- Heater Capacity: 6 – 36 kW (model-based)
- Pump Flow: 20 – 100 L/min
- Cooling Type: Direct or Indirect (based on medium)
- Power Supply: 3 Phase, 415V, 50 Hz
Advantages of Mould Temperature Controllers
- Improves part consistency and reduces warpage
- Lowers rejection rate and increases molding precision
- Fast response system with accurate temperature control
- Robust design for 24/7 industrial operation
Frequently Asked Questions (FAQs)
It maintains consistent mould temperature during molding, improving product quality and reducing cycle times.
Water type is used for up to 120°C, while oil type handles higher temperatures up to 200°C.
Yes, safety features like overheat protection, relief valve, and alarms ensure safe operation.
Yes, it provides both heating and cooling functions via an automatic control system.
